Flexim FLUXUS G608 Portable Ultrasonic Gas Flow Meter in Hazardous Areas

The Flexim FLUXUS G608 portable gas flow meter is based on the widely used, highly reliable and versatile G601, but has been specifically engineered for its use within hazardous areas and is FM Class I, Div. 2 approved. It is an ideal solution for gas flow measurement in potentially explosive areas, whether for a temporary replacement of a stationary flow meter, check metering or service operations. Due to its certification, users are freed from obtaining a Hot Work Permit, making access to hazardous areas much easier and less time consuming. An extremely resistant carbon fiber housing, together with its rugged transducer design, give the G608 high impact protection as well as resistance against oil, water and many other liquids. Accuracy: Measurement uncertainty at the measuring point (volumetric flow rate): ±1…3 % of reading ±0.02 ft/s Repeatability: 0.15 % of reading ±0.02 ft/s Range: Flow Velocity Range: 0.03 to 115 ft/s, depending on pipe diameter Certifications/Approvals: FM Class I /Div 2 Power Supply: Li-ION 7.2V/6.2Ah Operat. time >25h Transducers Available: Shear wave/Lamb wave Pipe Size: 0.28 inch to 63 inch Temperature Range: -40°F to +392°F Input: Pt100/Pt1000 System Configuration and Installation: For more detailed Information please download the Technical Specifications
